Description
M80 is a Gigabit enterprise router designed by IP-COM for high requirement users, such as enterprises, hotels, and community bandwidth operations. M80 uses a dual core 1.4GHz network special processor, equipped with the professional design of DDR3 high speed memory. The equipment adopts IP-COM enterprise system firmware and built-in intelligent AP management system, which can automatically distribute and maintain automatic AP configuration. The device provides WEB account password authentication, WEB key authentication, WeChat WiFi authentication and PPPoE Server access authentication mode, which can meet the access authentication requirements under different scenarios. In addition, it also supports multiple WAN bandwidth superposition and load balancing, behavior management, VPN, intelligent bandwidth control, USB file sharing and many other enterprise functions.
- ARM dual core 1.4GHz network processor,The maximum users can be 300
- 5*10\100\1000Mbps network port, 1*USB interface
- It can manage IP-COM all AP, support maximum management 32APs, support configuration automation
- Built-in WEB single key authentication, WEB account password authentication, WeChat authentication
- SMS authentication and other authentication methods
- Support QVLAN, maximum configurable 15 QVLAN
| Hardware Paramenters | |
|---|---|
| CPU | ARM Double core 1.4GHz |
| RAM | 4Gb |
| Flash | 1Gb |
| Ports | 5*GE(Max 4 WAN 、Max 4 LAN )、1*USB |
| Dimensions | 294*178.8*44(mm)(LxWxH) |
| Power | Build-in power switch |
| Enviorment | Working Temperature:0~40°C Storage Temperature:-40~70°C Working Humidity:10%~90%RH Storage Temperature:5%~90%RH |
| Software Paramenters | |
| Working Model | Rounter Model |
| AC Function | Manage all AP of IP-COM |
| Behavior Management | Base on URL,Base on IP/MAC address |
| Access Authentication | WEB authentication, WeChat authentication, PPPoE server authentication |
| Network Speed Control | Intelligent Control，Custom Control |
| VPN | PPTP，L2TP，IPSEC |
| Virtual Server | DMZ，Port mapping，DDNS，UPNP |
| USB Application | USB File sharing |
| Security Setting | IP-MAC Binding，attack defense |
| Static Rounter | supports |
| LAN Port VLAN | supports QVLAN |
| icloud | Online upgrade of system software |
| System Tools | Timing reboot，Feature library upgrade，Collocation back-up/recovery |
| System State | User View，Traffic statistic, System log |
| Performance Paramenters | |
| Maximum number of User | 300 |
| AP Management | Maximum number of 32 Aps |
| Web User | 500 |
| PPPoE User | 400 |
| VPN User | 32 |
| QVLAN | 15 |
