CMR IP-IR3S24 3.0MP 3.6MM

  • Description
  • Catalouge

Description

Video & Audio
Audio In N/A
Video
ROI Each ROI to be configured separately
Recording
Recording Resolution 3MP (2048 x 1536 ), 1080P (1920 x 1080 ), 720P (1280 x 720 ), D1, CIF, 480 x 240
Record Rate 60Hz : 3MP (1 ~ 30fps) / 1080P (1 ~ 30fps) / 720P (1 ~ 30fps ); 50Hz : 3MP (1 ~ 25fps) / 1080P (1 ~ 25fps) / 720P (1 ~ 25fps )
Bit Rate 128 Kbps ~ 6 Mbps
Encode VBR / CBR
Quality 5 Levels VBR, Freely adjustable under CBR
Camera
Image Sensor 1/2.8″ 3MP Aptina Sensor
Effective Pixels 2048 x 1536
Electronic Shutter 1/25s ~ 1/100,000s
Mini. Illumination 0.07 lux @F1.2,AGC ON; 0 lux with IR
Camera Features
IR LEDs 21 IR
IR LEDs Distance 33 ~ 66ft (10~20m)
Day / Night ICR auto switch
Noise Reduction 3D Noise Reduction
WDR Digital-WDR
Lens
Focal Lens 3.6 mm @ F1.6, horizontal field of view:85.8°
Auxiliary Interface
Alarm Motion Alarm
Network
Ethernet RJ45
Smart Phone iPhone, Android
General
Power Supply DC 12V / PoE
Power Consumption < 3W (ICR OFF) / <5W (ICR ON)
Working Environment -4℉ ~ 122℉ (-20℃ ~ 50℃),10% ~90% Humidity
Protection IP66
Dimensions 2.8″ x 6.1″ (Φ 70 × 156mm)
Weight 0.77Lbs (350g)
